Main characteristics

◆ Intelligent temperature controller, accuracy ±1 % , working temperature range: 60-220℃

◆High rate increase of temperature, only 40 seconds needed to rise from room temperature to 180℃ :

◆ Adjustable fixed-force system, suitable for sealing paper-plastic bags, 3D paper-plastic bags and paper-paper bags;

◆ Advanced flat ceramic heating components, high-temperature stability, long life expectancy and high heat efficiency.

Specification

◆Sealing speed 10m/min                     automatically controlled by sensor

◆ Seal width 12mm         Voltage: 220V 50Hz(Optional)             Power: 500W

● Seal strength meets YY/T 0698.5-2009 requirement      Weight: 15kg

◆ Seal margin: 0-35mm adjustable            Dimension: 490x260x136(mm)
