♦ Scope of application

This product is suitable for pharmaceutical scientific research and chemical industry and other units, can be dressings, glassware media and other disinfection.



♦ Sterilization principle

This series of sterilizer is designed using the principle of wet heat killing microorganisms, its principle is the use of gravity displacement principle, so that steam in the sterilizer from the top down, the cold air is discharged from the lower exhaust hole, the discharged cold air is replaced by saturated steam, the use of steam release latent heat to sterilize items.



♦ Intelligent microcomputer control system

Using LED digital control system, After sterilization finished, sterilizer will automatic alarm and shut down.



♦ Electric interlock device

The control system can real time supervision the sterilizer chamber's temperature and pressure. Only under the safety temperature and pressure can open the sterilizer's cover.



♦ The structure of cover's opening

Using hand wheel rotary type cover to improve sealing and safety performance.



♦ Preset program

Can preset fixed program that sterilize.



♦ Memory storage system

Store the last operation program so convenient next operation



♦  Interface cheek

Provide temperature and pressure cheek interface, convenient to check multiple position temperature measurement.



♦ Digital display screen

Digital display screen and working indicator light display running state.



♦ Safety devices

Adopting the safety interlock structure of electrical and mechanical interaction to ensure that the interlocking device locks the lid handle when there is pressure inside the pot to avoid opening the lid when there is pressure inside the pot.



♦ Technical Parameter

Parameter/Model	YF-LDZH-100L	YF-LDZH-150L	YF-LDZH-200L
Configuration	Semi-auto
Material	Stainless steel
Pot wall thickness (mm)	3.0(Reference)
Gross Weight (kg)	188	213	238
Voltage/Power	380V/6kW
Package size (mm)	760x800x1340	760x800x1530	760x800x1720
Product size (mm)	630x700x1200	630x700x1400	630x700x1600
Chamber volume (DxH mm)	500x550	500x760	500x1000
Basket size (DxHmm)	470x230(2PCS)	470x230(3PCS)	470x230(4PCS)
Time setting range	1~99 h
Rated working pressure	0.217MPa
Temperature setting range	50~134℃
