♦ Scope of application

This product is suitable for pharmaceutical scientific research and chemical industry and other units, can be dressings, glassware media and other disinfection.

♦ Sterilization principle

This series of sterilizer is designed using the principle of wet heat killing microorganisms, its principle is the use of gravity displacement principle, so that steam in the sterilizer from the top down, the cold air is discharged from the lower exhaust hole, the discharged cold air is replaced by saturated steam, the use of steam release latent heat to sterilize items.



♦ Intelligent microcomputer control system

Using LED digital control system, After sterilization finished, sterilizer will automatic alarm and shut down.



♦ Interlock device

The control system can real time supervision the sterilizer chamber's temperature and pressure. Only under the safety temperature and pressure can open the sterilizer's cover.



♦ Structure of cover's opening

Using hand wheel rotary type cover to improve sealing and safety performance.



♦ Preset program

Can preset fixed program that sterilize.



♦ Memory storage system

Store the last operation program so convenient next operation



♦ Interface cheek

Provide temperature and pressure cheek interface, convenient to check multiple position temperature measurement.



♦ Digital display screen

Digital display screen and working indicator light display running state.



♦ Safety devices

Adopting the safety interlock structure of electrical and mechanical interaction to ensure that the interlocking device locks the lid handle when there is pressure inside the pot to avoid opening the lid when there is pressure inside the pot.



♦ Technical Parameter
