 Design pressure: 0.3Mpa                                                            Design temperature: 150°C;

 Maximum working pressure: 0.23Mpa                                        Maximum working temperature: 136°C

 Temperature display range: 0~200°C                                         Pressure display range: 0—0.4Mpa

 Sterilization temperature selection: 105~136°C                          Sterilization time range: 0~99 minutes;

 Dissolution temperature: 40~100°C                                             Holding temperature: 40~60°C

 Chambers and cartridges: 316L stainless steel



► Using microcomputer control technology, the whole process is automatically controlled by program.

► 7-inch touch screen automatically displays operating process status, temperature, pressure, time and other parameters and fault alarm information.

► There are 7 predetermined programs, and 100 programs can be expanded and saved.

► Separate feed port for adding various additives.

► Built-in air compressor for pressure maintenance in the cooling phase.

► Stir continuously by magnetic stirrer to ensure that the medium is well mixed and the temperature is uniform.

► PT-100 flexible temperature sensor is used to directly detect medium temperature.

► It has a USB interface, which can output and store sterilization records.

► Micro printer can be optionally configured to record the whole process of sterilization and fault alarm information in real time.

► The liquid program has the function of automatic control of cooling back pressure to avoid the overflow of the medium during cooling.

► Horizontal sliding quick door structure, self-rising sealing, simple and safe operation.

► Throughout the process, the medium is completely mixed, heated, sterilized, and cooled to the set dispensing temperature. The temperature of the medium is always maintained at the set dispensing temperature during the dispensing process.

► Efficient heating and cooling: High-quality heating elements ensure fast heating. The water circulation in the media container jacket ensures rapid cooling. The hot deionized water is continuously cooled by a heat exchanger. The total cycle time is 60 to 120 minutes and includes heating, sterilization and cooling, depending on the size of the vessel, the amount of medium and the temperature of the cooling water. The supporting pressure of sterile filtration prevents the medium from foaming or overflowing.



►Over-temperature automatic protection device: When the set temperature is exceeded, the system will automatically cut off the heating power supply, and the sound and light alarm will be given.

► Anti-dry burning protection device: When the heating pipe is dry boiled due to low water level, the system will automatically cut off the heating power supply, and sound and light alarm.

► Door safety interlock device: Only when the door is closed in place, the power supply can be turned on to heat and generate steam; There is pressure in the inner chamber and the door cannot be opened.

► Overpressure automatic pressure relief safety valve: when the opening pressure of the safety valve is exceeded, the safety valve is opened to relieve pressure.

► Thermal insulation door cover: The sterilization door is insulated with a door cover made of thermal insulation material, which is both aesthetically pleasing and can prevent the operator from burning.
